Explosion Proof Connector Explosion Proof Unions SU Series

Name: Explosion Proof Connector Explosion Proof Unions SU Series
Brand: SUREALL TECHNOLOGY LIMITED

Advantages

Class I Division 1,Group A,B,C,D

Zone 1, Zone 2

Class II Division 1,Group E,F,G

Zone 21, Zone 22

Class III

Type 4X，IP66

Ex d IIC Gb

Max. M63x1.5 or NPT2"

Ex tb IIIC Db IP66

Advantages of Explosion Proof Ethernet Connectors

Specification 

Designed with detachable assembly to dismantle into two parts, there is no need to remove the heavy explosion proof lighting or explosion proof enclosure, SU series explosion proof connector worked as explosion proof 3 piece coupling to separate the housing and conduit easily. This explosion proof reducing bushing can be used as flame proof connector to meet class 1 division 2 conduit requirements to connect the explosion proof junction box with conduit, the explosion proof panel with conduit flexibly to future maintenance, replacement for mounting kit and project turnarounds.

 Features

Selection Table

Data Sheet

Outline Dimensions

Features
Explosion Proof Connector SU Series

M/M, One end is male thread, the other is male thread

M/F, One end is male thread, the other is female thread

F/F, One end is female thread, the other is female thread

3 piece structure, optional o-ring sealing washer for soft tight performance

Selection Table
Explosion Proof Connector SU Series

Data Sheet
Explosion Proof Connector SU Series

Compliaces	IEC Standard IEC60079-0, IEC60079-1, IEC60079-7, IEC60079-31 Ex d IIC Gb Ex tb IIIC Db IP66 Zone 1, Zone 2 Zone 21, Zone 22
	EU Standard EN60079-0, EN60079-1, EN60079-7, EN60079-31 II 2 G Ex d IIC Gb II 2 D Ex tb IIIC Db IP66 Zone 1, Zone 2 Zone 21, Zone 22
	NEC & CEC Standard Class I, Div.1, Group A, B, C, D Class II, Div.1, Group E, F, G Class III
	UL Standard UL844, UL1598, UL1598A
	CSA Standard CSA C22.2 No.137
Material	Nickel Plated Brass / 304 Stainless Steel / 316 Stainless Steel
IP Grade	Wet Locations, Type 4X, IP66
Ambient Temperature	-40℃~ +100℃ / -40°F ~ +212°F
