Explosion Proof Connector Adaptors SA Series

Name: Explosion Proof Connector Adaptors SA Series
Brand: SUREALL TECHNOLOGY LIMITED

Advantages

Class I Division 1,Group A,B,C,D

Zone 1, Zone 2

Class II Division 1,Group E,F,G

Zone 21, Zone 22

Class III

Type 4X，IP66

Ex d IIC Gb

Max. M63x1.5 or NPT2"

Ex tb IIIC Db IP66

Specification 

Born for connecting armored cable exposed under the mechanical impact and full sealing for joint thread with explosion proof enclosure, SGA series explosion proof cable gland can hold the cable through attaching the rigid conduit directly with metal explosion proof lighting, metal explosion proof junction box, especially metal sheet explosion proof panel in hazardous location. This hazardous area cable glands are widely used in class 1 div 1, gas group A, B, C, D and zone 1 gas group IIC.

 Features

Selection Table

Data Sheet

Outline Dimensions

Features
Explosion Proof Connector SGA Series

Extra armor layer pinch structure for armored cable

Wide thread size from M16x1.5 to M63x1.5, from NPT 3/8" to NPT 2"

Optional seal washer, serrated washer, locknut, earth lug and sheath

Selection Table
Explosion Proof Connector SGA Series

Data Sheet
Explosion Proof Connector SGA Series

Compliaces	IEC Standard IEC60079-0, IEC60079-1, IEC60079-7, IEC60079-31 Ex d IIC Gb Ex tb IIIC Db IP66 Zone 1, Zone 2 Zone 21, Zone 22
	EU Standard EN60079-0, EN60079-1, EN60079-7, EN60079-31 II 2 G Ex d IIC Gb II 2 D Ex tb IIIC Db IP66 Zone 1, Zone 2 Zone 21, Zone 22
	NEC & CEC Standard Class I, Div.1, Group A, B, C, D Class II, Div.1, Group E, F, G Class III
	UL Standard UL844, UL1598, UL1598A
	CSA Standard CSA C22.2 No.137
Material	Nickel Plated Brass / 304 Stainless Steel / 316 Stainless Steel
IP Grade	Wet Locations, Type 4X, IP66
Ambient Temperature	-40℃~ +100℃ / -40°F ~ +212°F
