Explosion Proof Panel Ex d 11b Explosion Proof Panelboards SPN-d-IIB Series

Name: Explosion Proof Panel Ex d 11b Explosion Proof Panelboards SPN-d-IIB Series
Brand: SUREALL TECHNOLOGY LIMITED

Advantages

Class I Division 1,Group C,D

Zone 1, Zone 2

Class II Division 1,Group E,F,G

Zone 21, Zone 22

Class III

Zone 21, Zone 22

Ex d IIB T6 Gb

Max.630A

Ex tD A21 T80℃ IP66

Built-in Terminal blocks

Advantages of Explosion Proof Panelboards

Specification 

To be suitable for class 1 div 1, group C, D and zone 1 group IIB, SPN-d-IIB series explosion proof panel have flame proof Ex d type aluminum housing and internal general type circuit breaker, control pushbuttons, indicators and can resist the mostly used hazardous condition excluding acetylene and hydrogen atmosphere. Flexible operating handle of explosion proof panelboards is designed for free switch off on the front cover access and optional surface and free-standing bracket bring convenience for installation.

 Features

Selection Table

Data Sheet

Outline Dimensions

Features
Explosion Proof Panel SPL-d-IIB Series

Rigorous overall layout for electrical components inside the housing to reduce the potential of explosion

Low surface roughness plane joint flame proof path to disperse explosion energy occurs in the housing

Four-side available hubs to arrange the incoming and outgoing cable as requested

Buttons, indicator, switches are clearly install in front surface for accurate controlling

Explosion Proof Starter Disconnect Enclosure

Selection Table
Explosion Proof Panel SPL-d-IIB Series

Data Sheet
Explosion Proof Panel SPL-d-IIB Series

Compliaces	IEC Standard IEC60079-0, IEC60079-1, IEC60079-31 Ex d IIB T6 Gb Ex tb IIIC T80℃ Db IP66 Zone 1, Zone 2 Zone 21, Zone 22
	EU Standard EN60079-0, EN60079-7, EN60079-31 II 2 G Ex d IIB T6 Gb II 2 G Ex tb IIIC T80℃ Db IP66 Zone 1, Zone 2 Zone 21, Zone 22
	NEC & CEC Standard Class I, Div.1, Group C, D Class II, Div.1, Group E, F, G Class III
	UL Standard UL844, UL1598, UL1598A
	CSA Standard CSA C22.2 No.137
Material	Copper-free aluminium,grey
Rated Voltage	Max.690V AC
Rated Current	Max.630A
IP Grade	Wet Locations, Type 4X, IP66
Ambient Temperature	-60℃~ +55℃ /-76°F ~ +131°F
Cable Entry	Metric or NPT thread type plugs (standard) or cable glands
Buite-in Components	Main Switch(MCB or MCCB),Branch Switch(MCB or MCCB),Indicator,Terminal etc.
