Explosion Proof Sealing Fittings Couplings SCS Series

Name: Explosion Proof Sealing Fittings Couplings SCS Series
Brand: SUREALL TECHNOLOGY LIMITED

Advantages

Class I Division 1,Group A,B,C,D

Zone 1, Zone 2

Class II Division 1,Group E,F,G

Zone 21, Zone 22

Class III

Type 4X，IP66

Ex d IIC Gb

Max. M63x1.5 or NPT2"

Ex tb IIIC Db IP66

Advantages of Class 2 Division 2 Conduit Requirements

Specification 

SCS series explosion proof conduit sealing, known as explosion proof sealing fitting, conduit seals hazardous locations, conduit seal, sealing fitting, eys conduit seal fittings, eyd conduit fitting, explosion proof seal tight, is flame proof conduit sealing with sealed compound to connect conduit to stop the flammable substance entering through the joint. Explosion proof conduit sealing couplings can meet class 1 division 2 conduit requirements, class 1 division 2 conduit sealing requirements based on eys fittings installation instructions.

 Features

Selection Table

Data Sheet

Outline Dimensions

Features
Explosion Proof Conduit Fittings SCS Series

Separate access for pouring explosion proof compound

Varied type for requested install environment

Selection Table
Explosion Proof Conduit Fittings SCS Series

Explosion Proof Conduit Sealing Fittings Couplings SCS Series

Data Sheet
Explosion Proof Conduit Fittings SCS Series

Compliaces	IEC Standard IEC60079-0, IEC60079-1, IEC60079-7, IEC60079-31 Ex e IIC Gb Ex tb IIIC Db IP66 Zone 1, Zone 2 Zone 21, Zone 22
	EU Standard EN60079-0, EN60079-1, EN60079-7, EN60079-31 II 2 G Ex d IIC Gb II 2 D Ex tb IIIC Db IP66 Zone 1, Zone 2 Zone 21, Zone 22
	NEC & CEC Standard Class I, Div.1, Group A, B, C, D Class II, Div.1, Group E, F, G Class III
	UL Standard UL844, UL1598, UL1598A
	CSA Standard CSA C22.2 No.137
Material	Copper-free aluminium
IP Grade	Wet Locations, Type 4X, IP66
Ambient Temperature	-40℃~ +100℃ / -40°F ~ +212°F
